Chapter 6 — Setting Up the Printer
54 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
Reading the Current Setup
The printer’s current setup values can be read from the printer’s
display window by browsing through the Setup Mode.
You can list the printer’s current setup values by printing test label
“Setup Info” in the Setup Mode or by using Intermec Shell.
The current setup values can be sent to the host via the standard
serial communication channel using a SETUP WRITE
"uart1:" statement. See the Intermec Fingerprint Developer’s
Guide (P/N 934-019-XXX).
Setup Parameters
Serial Communication
The serial communication parameters control the
communication between the printer and the connected computer
or other devices on the serial port. "uart1:" and the optional serial
ports "uart2:","uart3:", "uart4:", and "uart5:". The optional
ports require one or two optional interface boards. The printer’s
firmware detects if an interface board is installed in the printer
and presents additional sets of communication setup menus
depending on type of communication (refer to Chapter 7, “Setup
Mode” and the overviews depicted in Appendix E).
Media type Label (w Gaps)
Paper type Thermal transfer
Ribbon constant 90
Ribbon factor 25
Label offset
0
Low diameter (ribbon)
0 dots
Contrast ±0%
Print Defines
Print speed
100 mm/sec.
Media:
