Intermec EasyCoder PM4i User Manual

Appendix D — Intermec Supplies
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 151
Bar Code Directions
In the tables on the pages that follow, different maximum print
speeds may be recommended depending on the direction of
possible bar codes in the printout. Generally, ladder style bar
codes are more demanding and may require a lower print speed,
especially in connection with a large media roll and/or negative
start adjust values (see “Print Speed” in Chapter 6). The
illustration below shows how the two type of bar code directions
relate to the media feed direction.
Picket Fence
Ladder
Feed
Direction
Dir 1 & 3
Dir 2 & 4

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
