Intermec EasyCoder PM4i User Manual

Chapter 12 — Adjustments
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 119
Printhead Pressure
The pressure of the thermal printhead against the direct thermal
media is factory-adjusted. However, the use of thicker or thinner
media than normal could require the printhead pressure to be
readjusted.
Using a straight-slot screwdriver, turn the adjustment screw
clockwise for more pressure (+) or counterclockwise for less
pressure (-). Print a few labels, preferably test labels (see “Setting
Up the Printer” on page 51) and check the printout. Increased
pressure generally gives a darker printout and vice versa. Repeat
until the desired result is obtained.
To return to the factory setting, tighten the screw (+) as far as it
goes and then loosen it (-) four full turns.
Do not use a higher printhead pressure than necessary,
because it may increase the wear of the printhead and shorten
its life.
Adjustment
screw

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
