Intermec EasyCoder PM4i User Manual

Chapter 6 — Setting Up the Printer
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 53
Intermec Direct Protocol
• Use setup strings to change individual setup parameters
remotely from the host.
See the Intermec Fingerprint Command Reference Manual
(P/N 937-005-XXX).
Default Setup
The printer’s default setup is listed below (assuming no options
installed):
Ser-Com "uart1:"
Baud rate 9600
Character length 8 bits
Parity
None
Stop bits
1 bit
RTS/CTS
Disable
ENQ/ACK
Disable
XON/XOFF; data to host
Disable
XON/XOFF; data from host
Disable
New line
CR/LF
Receive buffer
1024 bytes
Transmit buffer
1024 bytes
Feedadjust
Startadjust 0 dots
Stopadjust 0 dots
Media:
X-start (8 dots/mm = 203.2 dpi)
X-start (11.81 dots/mm = 300 dpi)
24 dots
36 dots
Width (8 dots/mm = 203.2 dpi)
Width (11.81 dots/mm = 300 dpi)
832 dots
1248 dots
Length (8 dots/mm = 203.2 dpi)
Length (11.81 dots/mm = 300 dpi)
1200 dots
1800 dots

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
