Intermec EasyCoder PM4i User Manual

Chapter 11 — Maintenance
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 105
4 Never use any sharp tools for removing stuck labels. The
printhead and rollers are delicate.
Cleaning the Media Guides
Both parts of the label stop sensor, which controls the media feed,
are covered by plastic guides. The guides are transparent to allow
the light to pass between the two parts of the label stop sensor.
These areas must be kept clean from dust, stuck labels, and
adhesive residue.
If the printer starts to feed our labels in an unexpected way, pull
out the upper guide as described below and check for any object
that may block the beam of light (dust, stuck labels, adhesive
residue, etc.). If necessary, clean the guides using a cleaning card
or a soft cloth soaked with isopropyl alcohol. Do not use any
other type of chemical. Be careful not to scratch the guides.
Some Intermec RFID option kits use the media guide to house
the RFID antenna. Be extra careful not to damage the antenna
when following the procedure described below.
Isopropyl alcohol [(CH 3)2CHOH; CAS 67-63-0] is a highly
flammable, moderately toxic, and mildly irritating substance.

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
