Intermec EasyCoder PM4i User Manual

Appendix D — Intermec Supplies
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 153
HP05 TTR Coated
TTR Premium
TTR Premium
Board
TTR High Gloss
White
TTR
Polyethylene
TTR Gloss
Polyethylene
100
80
95
80
75
80
25
25
25
25
25
25
0
0
0
0
0
0
200
200
200
200
200
200
200
200
200
200
150
200
HP03 TTR High Gloss
Polyethylene
100 30 0 200 200
1 Exceeding the recommended print speed may cause the printhead to wear out
prematurely. If the ambient temperature is lower than +15°C (+59°F), decrease print
speed by 50 mm/sec.
2 Applies to printing of text, lines, boxes, images, and picket fence bar codes.
3 Applies to ladder bar codes.
4 Requires high printhead pressure (see Chapter 12 “Adjustments, Printhead Pressure”).
Thermal Transfer Printing; 8 dots/mm (203.2 dpi) (continued)
Type/
Speed
Name
Ribbon
Constant
Ribbon
Factor
Label
Offset
Max
Rec.
Dir.
1&3
2
Print
1
Speed
Dir. 2&4
3
Direct Thermal Printing 11.81 dots/mm (300 dpi)
Type/
Speed
Name
Label
Constant
Label
Factor
Max Rec. Dir.
Dir. 1&3
2
Print Speed
1
Dir. 2&4
3
To p
Coated/
Standard
Thermal Top
Board
4
Thermal Top
105
95
40
40
100
150
100
150
Non Top
Coated/
Standard
Thermal Eco
Thermal Eco
Board
4
90
75
40
40
150
150
150
150
To p
Coated/
High
Thermal Top
High Speed
80 40 150 150

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
