Chapter 3 — Starting Up
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 19
• Font Cards provide additional fonts that can be used as long
as the card remains inserted in the printer.
• Font Install Cards permanently install additional fonts in the
printer, which can be used even after the card has been
removed.
• Firmware Cards automatically replace the printer’s fi rmware,
usually with an updated version.
CompactFlash cards are widely used for consumer’s computer
products like digital cameras. You can get a certain protection
from theft by installing an optional plate that covers an inserted
CompactFlash card.
CompactFlash
memory card
Protection plate
with screw (option)
Note: Always switch off the power before inserting or removing a
memory card! The card will only fit in one way. A memory card is
only detected if it is inserted before the printer is started.

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
