Chapter 4 — Media Load
28 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
An optional label-taken sensor can hold the printing of the next
label in a batch until the present label has been removed, see
“Options” on page 83.
To perform the peel-off (self-strip) procedure
1 Open the front and side doors.
2 Turn the printhead lift lever clockwise to raise the printhead.
Note: Peel-off operation sets high demands on the media in
regard of label stiffness, release characteristics of the adhesive and
liner, resistance against electrostatic charging etc., so the labels
will be dispensed properly. Consult your media supplier or test
the media to ascertain that it is suitable for your application.

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
