EasyCoder PX4i and PX6i Service Manual 121

Chapter 11 — Paper Cutter

Hinge

Guide plates

(insert media between the plates)

Hinge

Guide plates

(insert media between the plates)

Hinge

EasyCoder PX4i Cutter

EasyCoder PX6i Cutter
