200 EasyCoder PX4i and PX6i Service Manual

Chapter 16 — Interfaces

Network extension cable

EasyLAN Ethernet

interface board

Light guideCable tie #T20 Torx screw

and spacer

RJ-45 Ethernet connector

("net1:")

Serial number label (MAC address)

RJ-45 Ethernet

connector
