Intermec EasyCoder PX6i Service Manual

1
J1
IC1
M1
C1
C10 C11
C13
C14C15
C16
C17
C18
C19
C2
C20
C21
C22
C23 C24
C26
C27
C28
C29
C30
C31
C32
C34
C35
C36
C37
C5
C7
C4
C6
C38
C12
C25
C3
C39
IC2
L3 L2
L1
IC3
Y1
R9
R5
R6
R7
R12
R13
R4
R11
R8
R1
R2 R3
J2
D1
C33
Y2
EasyCoder PX4i and PX6i Service Manual 201
Chapter 16 — Interfaces
Components
1-971645-26 EasyLAN Interface Board; Soldering side
1-971645-26 EasyLAN Interface Board; Component side

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
