LIP-9070 iPKTS User Guide
65
Menu Selections Input and function
7 Display MAC Address
Displays the Phone’s MAC address
8 Change Connect Mode
Set the iPECS connection mode, 1: Local, 2: Remote, 3: Local/Remote
9 Display Phone Version
View the software version of the phone
* SYSTEM
6 Set Forced Fwd Dest
Assign a destination for Forced Forward
7 Forced Fwd to Dest
Activate Forced Forward
8 Register Bluetooth
Enter a Bluetooth device for use
9 Bluetooth Usage
Pair and Connect a Bluetooth device
0 Hot desk Login
Log in to a Hot desk station
* Hot desk Logout
Log out of a Hot desk station
# Enter Admin Access the Keyset Admin, a password may be required
** Button assignment menus 8 and 9 do not display in the Station User Menu and are used only to assign a
function to a Flex button.
Configuring Flex Buttons
Access to the Station User Menu also permits the user to reconfigure the Flex buttons on the phone. Buttons can
be configured to call and monitor the status of another station, select an item from the Station User Menu or dial a
number from the iPECS Numbering Plan . In addition to the Station User Menu codes, certain additional button
Function codes may be available for Flex button assignment as shown in the Station User Codes chart in Appendix
section A.1. Not all Station User Menu codes can be assigned to a Flex button of all phones.
To configure a Flex button,
1. Touch the PGM button ( ).
2. Press the desired Flex button, the present function of the button displays.
3. Dial a Station Number,
Dial a number from the iPECS Numbering plan or
Press the PGM button and dial a Station User Menu code.
4. Press the Hold/Save button to store the new configuration.
5. Repeat steps 2 to 4 for additional button programming.
Note
° To use a button may require configuration of the iPECS to enable use of the feature by the station.
° The user may not be allowed to assign or modify buttons for outside access such as a CO Line button, a
Loop button, etc.
