WAVEform Subsystem
Copyright © ITECH Electronic Co., Ltd. 98
Chapter19 WAVEform Subsystem
WAVEform[:IMMediate] <WAVEform>,[WAVEform],[WAVEform]
This command is used to set and query the waveform in Normal mode. For the
waveform with parameters, the parameters are set to default values.
<wave> :
⚫ Sine
⚫ Square
⚫ Saw
⚫ Triangle
⚫ Trapezoid
⚫ Clipped-sine
⚫ DST-01(30)
⚫ Filename
Syntax:
WAVEform[:IMMediate] <WAVEform>,[WAVEform],[WAVEform]
Arguments
<"Sine"|"Square"|"Triangle"|"Saw"|"Trapezoid"|"Clipped-sine"|"DST-01(30)"|"filen
ame">,
<"Sine"|"Square"|"Triangle"|"Saw"|"Trapezoid"|"Clipped-sine"|"DST-01(30)"|"filen
ame">,
<"Sine"|"Square"|"Triangle"|"Saw"|"Trapezoid"|"Clipped-sine"|"DST-01(30)"|"filen
ame">,
*RST
Sine
Query syntax:
WAVEform?
Returns:
<string>
Example
WAVE "Sine" // Set the waveform to Sine.
WAVE "Sine","Saw","Square" // Set three channel waveforms separately,
valid under three-phase unbalanced or multi-channel.
WAVE?
