ITech IT8200 Series Programming Guide

SCPI status register
Copyright © ITECH Electronic Co., Ltd. 3
Bit name
Bit
Decimal
value
Definition
Questionable Status Register
DEV_TYPE
12--13
Device type(single phase/ three
phase/reverse phase)
(bit13:bit12->00b/01b/10b)
OPERATIO
N_MODE
14--15
Operation mode(source/load/current
source)
SENSE
16
65536
SENSE enabled
WORK_FU
NC
17--19
Work function
(NORMAL/LIST/SWEEP)
CONST_M
ODE
20--23
Constant mode（BIT23:BIT20）
AC:CC/CR/CP/CS/NCR->01b/11b/10b/
100b/110b;
DC:CV/CC/CP/CR/CC+CV/CR+CV/CP
+CV/CC+CR/CC+CV+CP+CR->
00b/01b/10b/11b/100b/101b/110b/111b
/1000b;
WORK_MO
DE
24
16777216
Work mode (AC/DC)
SURGE_SA
G
25
33554432
Surge and sag
EXT_ANAL
OG
26
67108864
Analog
SYNC_MO
DE
27
134217728
External Synchronization
RECTIFIED
28
268435456
Rectified mode
UPF
29
536870912
Unit power factor
LINE_TYPE
30
1073741824
Connection type(DeLta or WYE)
PHASE_LA
CK
31
2147483648
Phase lost
