Chapter3 SCPI status register
You can get the current status of the electronic load by reading the operation
status registers. The electronic load records the different status of the instrument
through the four status register group, the four status register group are: status
byte register, standard event register, query status register and operation status
register. Status byte register records the information of the other status
register.
The following table describes the status signals.
Bit name
Bit
Decimal
value
Definition
Questionable Status Register
OV
0
1
Over Voltage protection
OC_Rms
1
2
RMS Over current protection
OC_Peak
2
4
PEAK over current protection
OP_POSITI
VE
3
8
Over positive power protection
sync_unlock
4
16
External Synchronization unlock
UV
5
32
Under voltage
OT
6
64
Over temperature protection
UC
7
128
Under current protection
ERR_SENS
E
8
256
Sense error
SHARE
9
512
Current share error
RVS
10
1024
Input reverse
INH
11
2048
Input inhibit
PS
12
4096
protect state
OSC
13
8192
Oscillating circuit
UNR
14
16384
Unknown internal fault of instrument
OC_Dc
15
32768
Over current protection of DC mode
OV_Peak
16
65536
Over peak voltage protection
FE
17
131072
Frequency error
WDOG
18
262144
Watch dog protection
Operation Status Register
LIST_WTG
0
1
LIST watting for trigger signal
LIST_ACTI
VE
1
2
LIST is running
OFF
2
4
Input is off
CC
3
8
Constant current
CV
4
16
Constant voltage
CW
5
32
Constant power
CR
6
64
Constant resistance
CS
7
128
Constant apparent power
REMOTE_L
OCK
8
256
Remote lock
LOCAL_LO
CK
9
512
Local lock
RMT
10
1024
Remote mode
CAL
11
2048
Calibration
