Johnson Controls SABROE Unisab III Control User Manual

Menu level 1 Menu level 2 Menu level 3 Menu level 4
Control values Process temp. Values
Process out temp.
Process in temp.
Evap. level
Condensor level
Limits
Control
Limits (Chiller only)
Control (LP level control)
Control (HP level control)
User Values
User input 1 Limits
Control
Intermediate Values
Pressure Bar
Pressure Deg.
Temperature
(Two-stage recip. only)
Limits
Limits
Limits
History Shutdown
No. of shutdowns
Control state
Measured values
Input state
Output state
Table 4: Unisab III HMI menu tree
Unisab III control
22/319
Engineering manual - Unisab III 1.10
001930 en 2014.09
