8.3.1 Uploading new software version
Place the following files for e.g. software version 1.0.6.5, in a library with the following path
on the flash card: E:\UnisabIII\updates\1_0_6_5:
• UnisabIII_1065.strip - (program application, not visible in the file overview)
• ResourceBundles – (language file library)
• Vfd.dat - (data information for frequency drive)
Insert the flash card in Unisab III and follow the instruction described in section 8.2. Enter
boot loader and 8.3. Update. Update to upload the software update.
If the file version on the SD card is newer than the present software version, Unisab III will
ask if the software version should be updated when you insert the SD card and restart Unisab
III (i.e. pressing
F2
,
F3
,
F4
or power off/on).
First you will be prompted to accept.
If you answer Yes, updating (uploading) to version 1.0.6.9 will take place.
Unisab III is now updated to version 1.0.6.9 (including the 18 language files, VFD.dat and op-
tional configuration files on the SD card). Now restart Unisab III to make the software change
take effect.
Unisab III (boot) and communication set-up
256/319
Engineering manual - Unisab III 1.10
001930 en 2014.09
