Shutdown/alarm Id
Danbuss Profibus/
Modbus
Low process in temperature alarm + shutdown NA 96
Emergency stop shutdown NA 97
Low process out temperature alarm + shutdown NA 98
High process out temperature alarm + shutdown NA 99
Low-low oil pressure shutdown NA 104
1) May occur as alarm in MAN and AUTO.
2) Shutdown at prelubrication. Alarm during operation.
3) HPO/HPC only.
4) The shutdown Low oil pump pressure during operation applies to SAB 80. The shutdown is only activated at
a discharge pressure level below 16 bar.
5) Shutdown relay can be deactivated.
NA = Not available
Table 17: Shutdowns and alarms with identification numbers for reciprocating compressors
For the optional protocols RS2LAN, Profibus DP and Modbus TCP you can also find the ID
numbers in the dedicated manuals.
Alarms and shutdowns
62/319
Engineering manual - Unisab III 1.10
001930 en 2014.09
