Settings - Regulating parameters, SAB 330
Regulator type Factory set-
ting
SAB 330
Hydraulic Mechanical
Capacity control Nz 0 2
Pb 200 200
Min. pulse 1 2
Run time See note 1 See note 1
Vi slide control, compressors
with automatic Vi regulation
Nz 4 10
Pb 200 200
Min. pulse 1 1
Run time See note 1 See note 1
Table 22: Settings - Regulating parameters, SAB 330
Note 1. Run time factory settings are as follows:
SAB 330 S SAB 330 L SAB 330 E Others Unit
Cap. run time 41 56 74 60 sec.
Vi run time 19 24 31 60 sec.
Table 23: Run time factory settings
Note 2. Run time factory settings for SAB 120 → 355:
SAB 120 SAB 151 SAB 193 SAB 233 283 355 Unit
Cap. run
time
30 30 40 50 60 60 sec.
Vi run
time
NA NA 20 25 30 30 sec.
Table 24: Run time factory settings
Compressor control and surveillance
Engineering manual - Unisab III 1.10
001930 en 2014.09
73/319
