Juniper SRX300 Series Reference Guide

•
SIM lock and unlock capability
•
Always-on, dial-on-demand, and backup modes
•
Over-the-Air upgrade for modem firmware
Figure 10 on page 76 shows the front panel of the LTE Mini-PIM.
Figure 10: LTE Mini-PIM Front Panel
Table 45 on page 76 lists the components on the front panel of the Mini-PIM.
Table 45: LTE Mini-PIM Front Panel Components
DescriptionComponent
Two SubMiniature version A (SMA) connectors.Antenna connectors
Mini-USB Type-B port for monitoring and troubleshooting.Mini-USB port
Two slots, SIM1 and SIM2, for inserting the SIM cards. The LTE Mini-PIM supports
mini, micro, and nano SIMs. The mini-SIM can be inserted directly in the SIM slot. To
insert micro and nano SIMs, use the SIM adapters supplied with the Mini-PIM. The
Mini-PIM is shipped with two SIM adapters.
SIM slots
Indicate the status at a glance. For details on the LED indications, see “LTE Mini-Physical
Interface Module LEDs” on page 79.
LEDs
The LTE Mini-PIM supports two multi-band swivel-mount dipole antennas, which can be rotated 360 °.
You can rotate the antennas and select the angle at which the signal strength is high. Table 46 on page 76
lists the specifications for the antenna.
Table 46: Specifications for the LTE Mini-PIM Antenna
ValueSpecification
EDA-2010-4G0R2-A2 (Vendor: MAG.LAYERS)Part number
•
704~960 MHz
•
1710~2700 MHz
Operating frequency range
76

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
