KEB F6 User Manual

Parameter Descriptions
202
© 2024 KEB America, Inc.
DG05 Actual Torque
Calculated based on the rated torque, LM07 Motor Torque, and ru24 (the actual torque
%).
Displays Torque (Nm) by taking rated torque * % actual torque.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
-20000
20000
-
Nm
0
Basic
-14760.0
14760.0
lbft
-
0
DG06 Motor Current
Displays the measured actual apparent current.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
-1100
1100
A
-
0
Basic
DG07 Motor Speed
Displays the current RPM of the motor using the encoder RPM.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
-21474830
21474830
1/min
-
0
Basic
DG08 DC Volts
Displays actual DC link voltage.
Name
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
DC Volts
RO
RO
0
1000
-
V
0
Basic
DC Bus Voltage
0
1000
V
-
0
DG09 Magnetizing Current
Displays the motor's magnetizing current.
Motor Type
Range
Units
Default
Pass
Level
Ind.
PM
Min.
Max.
Imp.
Met.
RO
RO
-3200
3200
A
-
0
Basic
