KEEWAY 500ATV - Ignition System; Battery, Charging System; Brake System

1. SER
VICE INFORMATION
1-8
Brake System
Item
Standard Service
Limit
Brake lever play
0mm --
Brake disc thickness
4mm 3mm
Brake Pedal Play
0mm
Front brake
Brake disc thickness 4m
m
3mm
Battery、Charging System
Item Standard
Model
Perm
anent magnet AC type
Output
3- phase AC
AC m
agneto
Motor
Charging coil Resistanc
e (20℃)
0.2-0.3Ω
Rectifier Three-phase
annular rectification, Silicon controlled
parallel-connected regulated voltage
Capacity
12V18Ah
Fully charged 12.8V
Term
inal point
voltage
Insufficient
charge
<11.8V
Standard 0.9A/5~10H
Battery
Charging
curren
t/time
Quick
4A/1H
Ignit
ion system
Item Standard
Ignition CDI ignition
Type BKR6E (NGK)
Optional K6RTC
Spark Plug
Spark plug gap 0.6-0.8mm
Ignition tim
ing
Max. advanced angle
43°/
3500r/min
Ignition Above
200V
Peak voltag
e
Pulse 150V
Light、Fuse
Headlight
12 V 35 W/35.0 W × 2
T
ail/brake light 12 V 5 W/21.0 W × 2
Fuses:
Battery fuse
30A
Main switch
fuse 10A
Light fuse
20A
Power output fuse
10A
Fan fuse
10A
