KEEWAY 500ATV - Cylinder Head Cover and Cylinder Head Remove Check

6. Engine Removal;In
spection & Installation
6-27
4. Cylinder
head cover and cylinder head remove check
According to the list of instructions on the order
1
Hexagon flange boltsM6*28 10 Hexagon flange boltsM6*22
2
Clinder Head Cove 11 spring washer
3
Cylinder head gasket 12 Timing driven sprocket
4
Hexagon flange boltsM6*25 13 Hexagon flange boltsM10*190
5
The chain regulator assembly 14 washerΦ25*Φ10.5*2
6
The chain adjustment control gasket 15 Hexagon flange boltsM6*28
7
Hexagon flange boltsM6*20 16 Cylinder head combination
8
Cylinder head side cover 17 Cylinder head of cushion
9
The cylinder head side cover gasket 18 locating pinΦ15*20
