KEEWAY 500ATV - Brake Light Switch; Horn Switch; Indicator Light Switch; Turning Light Switch and Warning

13. Lighting, Instruments, Sw
itches
13-7
Turning light sw
itch and Warning
indicator
light switch
Horn Sw
itch
2 WD、4 WD、4WD Diff-Loc
k Switch
Faulty handl
ebar switch:
→
Replace (→8-12 or 8-
13).
Brak
e Light Switch
Disconnect brake light switch connector
and check
terminators for continuity
Hold the brake lever-----Co
ntinuity
Release the brake lever--- No continuity
No continuity: → Replace brake light switch
H
orn
Inspection:
Rem
ove front cover (→2-8)
Disconnect horn.
Co
nnect with a fully charged 12V battery and check if
the horn so
unds.
Faulty Horn: → Replac
e
13
