7. CARBURETOR
7-2
1. Carburetor Removal
Disassemble the carbu
retor in the following serial number:
Serial No Description Serial No Description
1
CARB ASSY 10HC-A73E-0000 13 Main Jet (MJ) 99101-939-1380(#140)
2
TOP COMP 1030-906-2100 15 STAR JET 99101-939-0600
4 SPG
1290-880-2000 17 FV COMP 16155-ZG8-L100
5 SPG
-SEAT 1229-801-7000 17-1 CLIP 0405-019-1000
6 JN
N425-PCA00 19 GASKET 0901-814-6000
7
VACCUME PIS
TON
20 S J N424-25B35(#40)
8 S.S
COMP 1034-868-2500
12 N
J 16164-NN1-0030
12-1 N
JH N413-03C00
To Next Page
