8. FRONT WHEEL, FRONT BRAKE，SUSPENSION，STEERING
8-1
Overhaul
Info……………………..…8-1 Brake System…………………………8-4
Troubleshooting………………….…8-2 Suspension……………………………8-7
Front Wheel………………………...8-3 Steering………………………………8-12
Overhaul I
nformation Operating cautions Notes
● Securely support the vehicle when overhauling the front wheel and suspension system.
● Refer to chapter13 for overhaul and inspection of lighting, instruments and switches.
● Do not overexert on the wheel. Avoid any damage to the wheel.
● When removing tire, use the special tire lever and rim protector.
Maintenance Standard
Item
Standard Service Limit
Longitudinal
0.8mm 2.0mm
Ri
m
Vibration
Lateral 0.8mm 2.0mm
Re
mained groove － 3.0mm
7±0.2PSI(47±1.5KPa)
－
Tire
Tire pressure
7±0.2PSI(47±1.5 KPa) －
Front
brake
Free play(brake lever)
0mm －
Tightening Torque
Nut, Tie-rod
45-50 N·m
Lock nut, steering stem
23-25N·m
Nut, front wheel axle
180-200 N·m
Fixing bolt/nut, absorber（front）
30-35 N·m
Fixing bolt/nut, absorber（rea
r） 30-35 N·m
Nut,front/rear rim
30-35 N·m
Nut, rear wheel axle
180-200 N·m
8
