KEEWAY 500ATV - The Cylinder Head Combination that Resolution

6. Engine Removal;In
spection & Installation
6-31
4.9
The cylinder head combination that resolution
According to the list of instructions on the order
1
T
ake tooth hexagonal flange su
r
nutM6
12
O-ringΦ2*Φ43
2
The cone set screw tightlyM6*17 13 camshaft
3 rockshaft
14
LO
CK CLAMP
4 Inle
t rocker assembly 15
Val v e
bearing plate
(see Z-04 lock clamps,
valve cap dish that split
)
5 copper
washerΦ22*Φ28*0.2 16 valve springΦ3.2*Φ23*42
6
Exhaust rocker combination 17 intake valve
7
Hexagon flange boltsM6*20 18 exhaust valve
8
thermostat housing 19 valve oil seal
9 Therm
ostat 20 spark plug
10
Hexagon flange boltsM6*20 21 Cylinder head components
1
1 Camshaft cover
6
