KEEWAY 500ATV - Cylinder and the Piston Remove Check

6. Engine Removal;In
spection & Installation
6-36
5. Cylinder
and the piston remove check.
According to the list of instructions on the order
.
1
Chain guide a 7 wrist pin
2
Hexagon flange boltsM10*78 8 piston assembly
3
Hexagon flange boltsM6*28 9 locating pinΦ15*12
4
cylinder combination 10 Tension rod bolt
5
cylinder head gasket 11 Chain tension rod
6
C form block circle 12 timing chain
5.1A
s shown in figure remove cylinder four hexagonal bolt
