1. BATTERY，CHARGING SYSTEM
11
-3
Overhaul standard
Ite
m
Standard
Mod
el
Permanent magnet alternator
O
utput 3-phase AC
A
C magneto
Resistance of charging coil (20℃) 0.2-0.3
Rect
ifier Type
3-phase loop rectification,
controllable parallel connection,
regulated voltage
bat
tery 12V18Ah
C
urrent Leakage Less than 1mA
Fully
-charged 12.8v
Volta
ge between terminals
Insufficient charge Less than 11.8V
St
andard 0.9A/5~10hours
Batt
ery
Charge current/time
Fast charge 4A/60minutes
