6. Engine Removal;In
spection & Installation
6-45
8.1
As shown in figure will be driven shaft block in special
the combination fixed, use the tool to loosen the M16 nut.
8.2
Active bevel gear check
● Chec
k the cone tooth gear tooth surface crack, point
or corrosion, so the defects, such as a crack, pitting
serious change is active bevel gear.
8.3 The driven shaft block bearing inspection
Use hand turn sluggish, bearing whether card bearing radial clearance is too large, if have, replace bearing.
6305Bearing radial clearance standards
0.013-0.028 mm
6
