KEEWAY 500ATV - Box Assembly

6. Engine Removal;In
spection & Installation
6-58
As shown in figure reverse gear shaft
assem
bly, reverse gear shaft to vice axis
tilt to success in the right.
13. Box assembly
1．According to the list, as shown in the
assem
bly sequence
1
Hexagon flange boltsM8*90 torsion25
N
6
Shift positioning spring
2
Hexagon flange boltsM6*105torsion10
N
7
Hexagon flange boltsM14*26 torsion30N.m
3
Hexagon flange boltsM6*85 torsion10
N
8A
l washerΦ6*Φ12*1.5
4
Hexagon flange boltsM6*95 torsion10
N
9
oil se
al Φ 12* Φ 25*7(see Z-10 install
a
instru
ctions）
5
Shift positioning steel ballsSR4.5 10 water seal（See Z-11 installation instructions
Close box use sealant
