KEEWAY 500ATV - Left the Combination Decomposition Remove Check

6. Engine Removal;In
spection & Installation
6-47
10.
Left the combination decomposition r
emove check.
Ac
cording to the list of instructions on the order
1
Hexagon flange boltsM6*20 16 O-RingΦ2.5*Φ27
2 spring
ring6mm 17
The output axis flange constructed
p
ut shaft flange construc
ted that split)
3 washerΦ6*Φ19*1.5
18 Hexagon flange boltsM8*28
4
Oil pump driven gear 19 Rear bearing cover
5
Hexagon flange boltsM6*45 20 Hexagon flange boltsM6*22
6
Hexagon flange boltsM6*50 21 front bearing retainer
7
Oil pump assembly 22 ball-bearing6205
8
Hexagon flange boltsM6*16 23 output shaft
9
Oil absorption plate assemblies 24 drivenbevel gear
10 f
iller opening
gasket
25 Bevel gear positioning sets
1
1 Points oil cover plate MATS 26 ball-bearing 6207
12
Points oil cover plate 27 Flange constructed positioning sets
13
W
ith the lock flange surface nut
M16
28 oil sealΦ35*Φ48*
8
14
taper washer 29 oil sealΦ25*Φ47*
1
see Z-08oil
that sp
lit)
15 O-ringΦ3*Φ16
6
