6. Engine Removal;In
spection & Installation
6-44
3. the de
pth standard：64.40-64.45 mm
8. Driven shaft block decompositi
on remove check
According to the list of instructions on the order
1
With the lock flange surface nut M16 6 Driven shaft block
2 washerΦ16*Φ32*2
7 C form block circle
3
Axle drive bevel pinion 8 Bridge driven gear
4
Hexagon flange bolts M6*22 9 driven shaft
5 Bearing
plate
