KEEWAY 500ATV - Overhaul Standard; Rear Wheel, Rear Brake, Suspension

9–1
9
. Rear Wheel、Rear Brake、Suspension
Overhaul
Info………………………………9-1 Rear brake………………………………9-4
Troubleshooting……………………………9-2 Rear suspension…………………………9-5
Rear wheel…………………………………9-3
Overhaul info:
Note:
● Securely support the vehicle when overhauling the rim
and suspension system.
● Use genuine parts of bolts and nuts for rear rim and suspension.
● Do not overexert on the wheels to avoid possible damage to the wheels.
● When removing tire from rim, use special tire lever and rim protector to avoid.
damage to the rim.
Overhaul standard
Item
Standard Limit
Longitudinal － 2.0mm Ri
m
vibration
Horizontal － 2.0mm
Re
mained
Tire Tread
－
1.6mm
Tire
pressure(fro
nt)
7±0.2PSI(47±1.5KPa) －
Rear
wheel
Tire
Tire
pressure(rea
r)
7±0.2PSI(47±1.5KPa) －
Rear
brake
Brake lever Free Play
10~15mm －
Tightening torque
Rear wheel axle nut
180-200N.m
Ri
m mounting bolt 45-50N.m
Front m
ounting bolt, Shock absorber 30-35N.m
Rear m
ounting bolt, Shock absorber 30-35N.m
