KEEWAY 500ATV - Rear Cover Assembly; Rear Cover Assembly Disassembly;Installation

2. V
ehicle body，Muffler
2-7
REAR COVER ASSEMBL
Y
Rem
ove:
Remove Seat (→2-2)
Re
move bolt 1
Remove fuel tank cap
Remove connector of taillight
Remove rear cover
Install fuel tank cap for fuel tank
Installation
Reverse the rem
oval procedure of installation.
REAR COVER ASSEMBL
Y DISASSEMBLY/INSTALLATION
1.
TAILLIGHT ASSEMBLY,L. 2.
TAILLIGHT
ASSEMBLY,R. 3.
NUT,CLIP（M6）
4.
WASHER（φ6）
5. SCREW(M6×16) 6.
LICENSE PLATE LIGHT
7.
SCREW,TAP（ST4.2×16）
8.
WASHE
R(φ6) 9.
REAR REFL
ECTOR
10.
NUT,CLIP（M6）
11.
NUT，FLANGE（M5）
12.
SCREW (M6×16)
13.
W
ASHER, RUBBER 14.
COVER,
LEFT LINE.RR 15.
COVER, RI
GHT LINE.RR
16.
EXPANSION
SCREW(M8×20) 17.
COVER,
TAIL LIGHT 18.
REAR COVER
