9–7
9
. Rear Wheel、Rear Brake、Suspension
Disassembly
Stabiliz
er Bar
Remove:
Bolt (6), Holder, Stabilizer (5), Pin, Split(8), Nut (9)
Remove Stabilizer Bar .
Installation:
Reverse the removal procedure for
installation
Right rear absorber
Removal:
Note: Securely support the vehicle when removing rear left and right absorbers.
Maintenance of rear absorbers only does not require removal of rear suspension.
Remove the following parts for rear right shock absorber：
(15) Bolt
(8) Nut
(20) Bolt
(8) Nut
Remove rear right shock absorber.
Installation:
Reverse the removal procedure for installation.
Rear Right Arm
Refer to front right Arm in Chapter 8 for the removal, inspection and installation of Rear Right
Arm
Rear Left Suspension
Refer to Rear
Right Suspension for the removal, inspection and installation of Rear Left Suspension.
