KEEWAY 500ATV - Screwing Moment of Important Bolts

1. SER
VICE INFORMATION
1-9
Scr
ewing moment of important bolts
Engine：
Sequence
num
ber
Item Thread
diameter mm
Torque
（N·m）
Remark
1
CRANKCASE M8×88 25
2 SP
ARK PLUG M14×1.25 20
3
SHIFT CAM/ SECONDARY
SHAFT/SECONDARY SHAFT
M8×32 30
4
REAR COVER,BEARING M8×28 25
5
OIL PUMP INSTALLING BOLTS M6×50/M6×45 10
6
UPPER LEFT COVER M6×32 10
7
MAGNETO COVER M6×30 10
8 SEA
T,MAGNETO M6×25 10
9 CO
VER,WATER PUMP M6×28 10
1
0 CYLINDER HEAD/ HOLDER,BEARING/
FRONT COVER,BEARING
M6×22 10
1
1 SIDE COVER, CYLINDER HEAD/ OIL
STRAINER/ CAMSHAFT/
M6×20 10
12 CV
T COVER,LEFT(LOWER) M6×18 10
1
3 GEAR POSITION SENSOR/ SHEAVE DRUM
ASSY/ HANDLE ASSY
M6×16 12
1
4 SHEAVE DRUM ASSY /THERMOSTAT/
TEMPERATURE SWITCH
M6×10 12
1
5 MAGNETO STATOR M5×12 6
1
6 GEARSHIFT SPRING M14×26 30
17 PRIMA
RY SHEAVE ASSY M12×160 80
18 CY
LINDER M10×78 65
19 CY
LINDER M10×70 65
2
0 HEAD CYLINDER,ASSY M10×190 70
2
1 DRAIN BOLT M10×16 30
2
2 SECONDARY SHEAVE ASSY M10×100 80
2
3 FLANGE,OUTPUT M16 100
2
4 CRANKSHAFT ASSY M28×1.5 55
25
DRIVE BEVEL GEAR M16 300
26 FL
YWHEEL ASSY M16 75
27
IMPELLER ASSY
,WATER PUMP
M7 10
28 OIL
PIPE,INLET M12×30 35
29
OIL PIPE A/ OIL PIPE B M10×28 35
30
OIL PIPE A/ OIL PIPE B M12×43 35
3
1 CRANKCASE M6×105 10
