KEEWAY 500ATV - Magneto that Fold Points

6. Engine Removal;In
spection & Installation
6-25
2.17 Magneto that fold points
1
Hexagon flange boltsM6*30 5 O-ringΦ2*Φ24.8
2
Hexagon flange boltsM5*12 6 O-ringΦ2*Φ129.5
3 Coil
assembly 7
Oil seal Φ 25 * Φ 38 * 7 (see Z-03 oil
split explain)
4
The supplied pan-head screwsM5*8 8 Coil fixed a
2.18 Magneto check：
As shown in figure magneto wire if there is broken
