KEEWAY 500ATV - Front, Rear Suspension

1. SER
VICE INFORMATION
1-1
1
FRONT, REAR SUSPENSION：
s.q. Item
Qty.
Thread diameter
mm
Torque
（N·m）
Remark
1
NUT
, STABILIZER 2
M10 45～50N
.m
2
BOL
T, STABILIZER HOLDER 4
M8×16 20～25N
.m
3
NUT
, FRONT/ REAR AXLE 4
M10 45-5
0N.m
4
BOL
T, FRONT/ REAR AXLE
SUPPORT 8
M8×16 23-2
5N.m
5
BOL
T, STEERING SHAFT 2
M8×55 23-2
5N.m
6
NUT
, STEERING ARM 1
M14 55-6
2N.m
7
BOL
T, HANDLEBAR 4
M8×55 23-2
5N.m
8
BOL
T, ENGINE(NETHER)
2 M12×24
0
45-5
0N.m
9
BOL
T, ENGINE HOLDER 8
M8×20 23-2
5N.m
10
BOL
T, ENGINE(REAR)
1 M12×14
5
45-5
0N.m
11
BOL
T, ENGINE REAR BRACKET
AND FRAME 4
M8×16 23-2
5N.m
12
BOL
T, FRONT/REAR DRIVE
SHAFT 8
M8×22 23-2
5N.m
13
BOL
T, FRONT BRAKE MASTER
CYLINDER
4 M8×20 23-2
5N.m
14
BOL
T, REAR BRAKE DISC
GUARD 2
M10×60 45-5
0N.m
15
BOL
T, REAR BRAKE MASTER
CYLINDER 2
M10×20 45-5
0N.m
16
BOL
T, FRONT/REAR BRAKE
DISC 12
M8×16 23～25N
.m
17
NUT
, BRAKE PEDAL 1
M10×1.
25
45～50N
.m
18
BOL
T, MASTER
CYLINDER.PEDAL BRAKE 2
M6×30 10～12N
.m
19
NUT
, FRONT/ REAR ARM ANG
FRAME 12
M10×1.
25
45～50N
.m
20
NUT
, FRONT KNUCKLE ANG
FRONT ARM
4 M12×1.
25
45-5
0N.m
21
NUT
, REAR KNUCKLE ANG
REAR ARM 4
M10×1.
25
45～50N
.m
22
BOL
T, GEARSHIFT UNIT 2
M8×20 23～25N
.m
23
NUT
, STEERING TIE-ROD 4
M10×1.
25
45～50N
.m
24
NUT
, FRONT/ REAR SHAFT SET 4
M20×1.
5
18
0～200N.m
25
NUT
, FRONT/ REAR SHOCK
ABSORBER 8
M10×1.
25
30～35N
.m
26
NUT
, RIM 16
M10×1.
25
30～35N
.m
1
