6. Engine Removal;In
spection & Installation
6-37
5.2
As shown in figure with glue like tapping cylinder
side parts took down the cylinder.
5.3 As shown in figure card ring plier take down
the piston pin CARDS ring and then taking
off the piston pin and the piston.
5.4Inspection of the cylinder
In the top surface with a 61.5 mm place not the
X and Y directions measuring cylinder diameters
●If it is not within the scope of the provisions, then replace the
cylinder block
Standard cylinder size limit
92.000-92.025
6
