6. Engine Removal;In
spection & Installation
6-62
Fixed a
coil assembly instructions
1.
Accordin
g to the list, as shown in the assembly sequence
1
Coil fixed seat 5 O-ringΦ2*Φ24.8
2 O-ringΦ2*Φ129.5
6 Hexagon flange boltsM6*30 torsion10N.m
3 oil
sealΦ25*Φ38*7 7 Hexagon flange boltsM5*12 torsion6N.m
4 Coil
assembly 8
The supplied pan-head screwsM5*8
torsion6N.m
Flat k
ey assembly instructions
The flywheel assembly instructions
