2. V
ehicle body，Muffler
2-9
Re
move connector of meter
Remove connector of headlight
Remove front cover assembly.
Installation
Reverse the rem
oval procedure of installation.
F
RONT COVER ASSEMBLY
DISASSEMBLY /INSTALLATION
1. METER ASSEMBL
Y
2.
WA
SH ER (
φ
5)
3. NUT
, FLANGE（M5）
4.
COVE
R, WATER TANK
5.
SCREW
(M6×16)
6.
NUT
,CLIP（M6）
7.
WA
SH ER ，RUBBER
8.
BA
TTERY COVER
9.
EXP
ANSION SCREW(M8×20)
10.
COVER,
LEFT LINE.FR
11.
COVER,
RIGHT LINE.FR
12.
FRONT
COVER(L)
13.
FRONT
COVER(R)
14.
SCREW
(M6×16)
15.
COVE
R，RADIATOR
16.
COVER,
VENT GRILLE
17.
HEADL
IGHT UNIT,L
18.
HEADL
IGHT UNIT,R
19.
WA
SH ER(
φ
5×
φ
15×1)
20. SCREW(M5×10)
21. HEADL
IGHT.L. FENDER
22. HEADLIGHT.R. FENDER
23. SCREW,TAP（ST4.2×16）
24. HORN
2
