KEEWAY 500ATV - Page 35

3. CHECK
S & ADJUSTMENT
3-3
Inspection
& Maintenance
○
：
Inte
rval
Check Item
Interval
Part Item
Daily 1/2 Year Annual
Standard
Handlebar Operation a
gility ○
Da
mage ○
Insta
llation
condition of
steering system
○
Steering
System
Steering
System
Sway of ball stud ○
Free play ○ ○ ○
Front: lever end 0mm
Front: lever end 0mm Brake pedal
Brake Ef
ficiency ○ ○ ○
Connecting
rod, oil pipe
& Hose
Looseness,
Slack and dam
age
○ ○
Front and rear
brake fluid level
○ ○ ○
Brake fluid should be above
LOW
ER limit
Brake
System
Hydraulic
brake and
brake disc
Brake disc
damage and wear
○ ○ ○
Replace when the thickness of
front brake disc is less than
3.5mm, rear brake less than
3.5mm
Tire pressure ○ ○ ○
Front tire ：47kPa
(7±0.2PSI)
Rear tire ：47kPa
(7±0.2PSI)
Chap and dam
age ○ ○
Groove depth and
abnorm
al wear
○ ○
No wear indication on the
surface of tire (the remained
depth of groove should not be
less than 3mm)
Loosened wheel
nut and axle
○ ○ ○
Sway of front
wheel bearing
○ ○
Driving
System
wheel
Sway of rear
wheel bearing
○ ○
Suspension
arm
Sway of joint
parts, rocker arm
damage
○ ○
Shock
absorber
Oil leak
age and
damage
○ ○
Buffer
System
Function ○
Front axle
Transm
ission,
lubrication`
○ ○
Rear axle
Transm
ission,
lubrication
○ ○
Drive-Tr
ain
system
Gear box
Transmission,
lubrication
○ ○
3
