5. REMOV
AL OF ENGINE, TRANSMISSION SYSTEM AND GEARSHIFT
5-1
Inspection
Information……………5-1 Removal and Installation of Front and Rear
Engine Removal and Installation…5-2 axle……………………………………5-5
Rem
oval and Installation of Gearshift…5-7
Inspection Information
Note:
●
W
hen removal Engine, please use jack to support the bodywork. Don’t damnify the
frame, body of Engine, bolt and cable etc.
● Please blind up the fram
e when removal the engine.
●
Don’
t removal engine from the bodywork when operating as follows:
—OIL PUMP
—CARBURETOR, AIR FILTER.
—COVER, CYLINDER HEAD,CYLINDER HEAD,CYLINDER,CAMSHAFT.
—CVT SYSTEM, CVT COVER.
—GEARBOX.
—RIGHT SIDE COVER, AC MAGNETO,WATE PUMP.
—PISTON﹑ PISTON RING, PISTON PIN.
●
Follow
ing operation require removal of engine from vehicle:
—CRANKCASE
Tightening torque:
Engine front rear m
ounting bolt（M12）：45～50N.m
Engine front rear mounting bolt（M8）：23～25N·m
Engine rear upper bracket mounting bolt（M12）:45～50N·m
Engine rear upper bracket mounting bolt（M8）:23～25N·m
5
