6. Engine Removal;In
spection & Installation
6-23
2.1
1 Shift shaft cover bolts removed, with
glue like light striking the shift shaft cover
to that of the case apart.
2.12
As shown in figure remove hexagonal bolt,
remove the shift shaft and change shift gears
clicked
2.13
As shown in figure remove the pipe clip, will feed line dial out
6
