6. Engine Removal;In
spection & Installation
6-29
4.4 A
s shown in figure remove tensioning device
on the bolts of tensioning device take spring.
4.5 As shown in figure remove tensioning device two
4.6 hexagonal bolt tensioning device take ontology.
4.7 As shown in figure remove the sprocket driven
the hexagonal bolt take down the sprocket.
6
