Keysight B2900 User’s Guide, Edition 5 4-37

Front Panel Reference

Trigger key group

Pressing the Trigger key displays the following softkeys for setting the trigger

parameters in detail and controlling the trigger system. See Figure 6-8 on page 6-28.

Config Opens a dialog box. See “Trigger Configuration dialog box” on page 4-38.

Initiate Displays the softkeys for selecting the device action to initiate (to go to the arm

layer of the trigger system). See Table 4-7.

Abort Displays the softkeys for selecting the device action to abort (to return to the idle

state of the trigger system). See Table 4-7.

Immediate Displays the following softkeys for selecting the arm layer or trigger layer for

sending the immediate trigger.

Trigger Selects the trigger layer.

Arm Selects the arm layer.

Selecting the layer displays the softkeys for selecting the device action to send the

immediate trigger. See Table 4-7.

Table 4-7 Softkeys to Select Device Action and Channel

Softkey label Description

ALL Selects the transient and acquire device actions.

Trans. Selects the transient (source output) device action only.

Acq. Selects the acquire (measurement) device action only.

On a 1-channel model, selecting the device action executes Initiate, Abort, or

Immediate for the specified device action.

On a 2-channel model, selecting the device action displays the following softkeys

for selecting the channel.

ALL Selects channels 1 and 2.

Ch 1 Selects channel 1 only.

Ch 2 Selects channel 2 only.

Selecting the channel executes Initiate, Abort, or Immediate for the specified

device action of the specified channel.
