5-22 Keysight B2900 User’s Guide, Edition 5
Front Panel Operations
To Execute Measurement
To Execute Measurement
This section describes the following measurement operations.
• “To Enable Resistance Measurement”
• “To Set Measurement Mode”
• “To Perform Spot Measurement”
• “To Stop Measurement”
• “To Set Measurement Time”
• “To Set Measurement Range”
• “To Perform Sweep Measurement”
• “To Set Measurement Trigger Parameters”
• “To Set Measurement Wait Time”
• “To Set Measurement Auto Range Operation”
• “To Enable or Disable Resistance Compensation”
To Enable Resistance Measurement
1. Press the View key to display the Single view. If the Range parameters are not
displayed, press the Hide XXXX assist key.
2. Move the field pointer to the Measure Ohms (resistance measurement range)
field. If this field is set to OFF, the resistance measurement is disabled.
3. Press the rotary knob to change the pointer status to EDIT.
4. Press the AUTO, FIXED, or V/I assist key to set the resistance measurement
operation. The pointer status is changed to MOVE.
For details on the resistance measurement operation, see “Range parameters” on
page 4-12.
To set the measurement range continuously, see “To Set Measurement Range”
on page 5-24.
