Function Details

Channel Grouping

This section applies only to 2-channel models. This function is used to control the

channel output timing automatically so that the channel keeps the output while the

other channel performs measurement.

The grouped channels start the source output in the order of channel number, then

start the measurement at the same time, and keep the output until the measurement is

completed. If delay time and wait time are set, this is adjusted by these values.

If the grouping is released, the channels work independently regardless of the

condition of the other channel.

To enable the channel grouping, press the Config > Common > Group > ON

function keys.

To disable the channel grouping, press the Config > Common > Group > OFF

function keys.

Conditions for the channels to group:

• Trigger source (Trigger value) must be the same.

• If the trigger source is set to TIMER, the trigger period (Period value) of the

source output trigger (transient action) must be the same. This is not applicable

if the trigger count (Count value) is set to 1.

NOTE About Wait Time

If wait time is set, channels cannot start measurement or source output change until

the wait time elapses. See “Wait Control dialog box” on page 4-31 for setting the

wait time.

For the grouped channels, the wait time starts at the timing of the last output change

(DC output change or pulse level transition from peak to base) by the last source

output channel.
