Keysight B2900 User’s Guide, Edition 5 5-25
Front Panel Operations
To Execute Measurement
The channel starts the specified voltage/current output. While the switch is
turned green, the channel continues the output and changes the value
immediately if it is changed.
8. Press the Trigger key.
The sweep measurement is performed and the measurement result is displayed
in a graph.
To Set Measurement Trigger Parameters
For details on this function, see “Trigger System” on page 6-27 and “Trigger
parameters” on page 4-17.
1. Press the View key to display the Single view.
2. Press the Show Trigger assist key to display the Trigger parameters.
3. Move the field pointer to the Trigger field.
4. Press the rotary knob to change the pointer status to EDIT.
5. Press the AUTO, SYNC, TIMER, or MANUAL assist key to set the trigger
type. The pointer status is changed to MOVE.
6. Move the field pointer to the trigger parameter setup field (Count, Delay, Period,
or Trigger in the Measure column).
7. Press the rotary knob to change the pointer status to EDIT.
8. Enter the trigger count (Count), trigger delay time (Delay), trigger period
(Period), or trigger source (Trigger).
9. Press the rotary knob or assist key to fix the setting value.
10. Repeat steps 6 to 9 for all parameters.
NOTE If you want to set the trigger parameters in detail, select the MANUAL trigger type
and use the Trigger Configuration dialog box opened by pressing the Trigger >
Config function keys. See “Trigger key group” on page 4-37.
To Set Measurement Wait Time
For details on this function, see “Measurement Time” on page 6-5 and “Wait
Control dialog box” on page 4-31.
1. Press the Config > Common > Wait function keys.
